Item Code: R11-6014W
Height x Width | Bars | BTU | Pipe Centre | projection |
300 x830mm | 18 | 2271 | 900 | 108mm |
300 x 999mm | 22 | 3166 | 1080 | 108mm |
300 x 1177mm | 26 | 3742 | 1260 | 108mm |
300 x 1400mm | 31 | 4462 | 1480 | 108mm |
300 x 1505mm | 33 | 4146 | 1575 | 108mm |
600 x 599mm | 13 | 3594 | 680 | 108mm |
600 x 999mm | 22 | 4977 | 900 | 108mm |
600 x 1177mm | 26 | 6038 | 1080 | 108mm |
600 x 1400mm | 31 | 7189 | 1260 | 108mm |
Feature:
Have a high quality, triple layer powder coat finish
Premium Mild Steeln Excellent Heat Dissipation
Safety tested at 10 bar of pressure
Salt spray tested to minimum of 200 hours
Non-leakage, non-rupture, non-toxic and non-pollution.
The water inlet/outlet size of radiators is G1/2"
Brackets And Fixings Included
Height x Width | Bars | BTU | Pipe Centre | projection |
300 x830mm | 18 | 2271 | 900 | 108mm |
300 x 999mm | 22 | 3166 | 1080 | 108mm |
300 x 1177mm | 26 | 3742 | 1260 | 108mm |
300 x 1400mm | 31 | 4462 | 1480 | 108mm |
300 x 1505mm | 33 | 4146 | 1575 | 108mm |
600 x 599mm | 13 | 3594 | 680 | 108mm |
600 x 999mm | 22 | 4977 | 900 | 108mm |
600 x 1177mm | 26 | 6038 | 1080 | 108mm |
600 x 1400mm | 31 | 7189 | 1260 | 108mm |
