Item Code:R7-48AD
Height x Width | Bars | BTU | Pipe Centre | Projection |
1800 x 300mm | 4+4 | 4202 | 380 | 81mm |
1800 x 452mm | 6+6 | 6304 | 530 | 81mm |
1600 x 300mm | 4+4 | 3753 | 380 | 81mm |
1600 x 452mm | 6+6 | 5630 | 530 | 81mm |
1800 x 608mm | 8+8 | 7318 | 678 | 81mm |
1600 x 608mm | 8+8 | 6465 | 678 | 81mm |
Feature:
Have a high quality, triple layer powder coat finish
Premium Mild Steeln Excellent Heat Dissipation
Safety tested at 10 bar of pressure
Salt spray tested to minimum of 200 hours
Non-leakage, non-rupture, non-toxic and non-pollution.
The water inlet/outlet size of radiators is G1/2"
Brackets And Fixings Included
Height x Width | Bars | BTU | Pipe Centre | Projection |
1800 x 300mm | 4+4 | 4202 | 380 | 81mm |
1800 x 452mm | 6+6 | 6304 | 530 | 81mm |
1600 x 300mm | 4+4 | 3753 | 380 | 81mm |
1600 x 452mm | 6+6 | 5630 | 530 | 81mm |
1800 x 608mm | 8+8 | 7318 | 678 | 81mm |
1600 x 608mm | 8+8 | 6465 | 678 | 81mm |
